ShapeWash 020S and 040S are compatible with using alcohol and isopropyl alcohol (IPA) as a cleaning solution.
The ShapeWash series uses the high-frequency vibration of the ultrasonic engine to drive the cleaning medium to form a high-pressure impact around the resin print, removing loose resin on the surface of 3D printed parts. Leaving you with the hardened clean parts ready for final.
The series has stainless steel housings, which can be adapted to industrial applications and are easy to clean after the ultrasonic tank has been used for several washes of parts. The ShapeWash 040S is the perfect choice if you need to print large-sized parts with the P400 series models or frequently require high-volume cleaning jobs.
Ultrasonic Cleaning Devices Dental 3D Printers Specification
| ShapeWash 020S |
|
| Main Parameters | |
| Washing volume | 240×135×100 mm |
| Technology | Ultrasonic Cleaning |
| Cleaning solvent | IPA, Alcohol |
| Compatible resin | Shape Materials Basic/Functional/Advanced/Denta Series |
| Environmental requirement | Ambient temperature 18~28℃ |
| Ultrasonic | |
| Ultrasonic frequency | 40kHz |
| Washing time | Customized setting(1-30 minutes) |
| Rinse tank | |
| Volume capacity | 3.2L |
| Raw material | SUS304 |
| Power | |
| Input | 100~120VAC, 50/60Hz 220~240VAC, 50/60Hz （Depending on the country/region） |
| Rated power | 120W |
| Size and weight | |
| Device size | 270×185×230mm |
| Device weight | 3.25kg |
| Package size | 340×250×445mm |
| Package weight | 4.3kg |
| ShapeWash 040S |  |
| Main Parameters | |
| Washing volume | 300×240×150mm |
| Technology | Ultrasonic Cleaning |
| Cleaning solvent | IPA, Alcohol |
| Compatible resin | Shape Materials Basic/Functional/Advanced/Dental Series |
| Environmental requirement | Ambient temperature 18~28℃ |
| Ultrasonic | |
| Ultrasonic frequency | 40kHz |
| Washing time | Customized setting (1-30 minutes) |
| Rinse tank | |
| Volume capacity | 10 L |
| Raw material | SUS304 |
| Power | |
| Input | 100~120VAC，50/60Hz 220~240VAC，50/60Hz （Depending on the country/region） |
| Rated power | 240W |
| Size and weight | |
| Device size | 380×290×280mm |
| Device weight | 7.2kg |
| Package size | 500×445×350mm |
| Package weight | 9.2kg |
Over 100 materials are available.
Experience the wide choice of materials on the market with broad access to many industry-leading materials for a variety of applications. Future-proof your business and stay up-to-date with recently validated 3D print materials thanks to RAYSHAPE's Open Material Architecture.
